MW 12 FLAT

Flat, flatter - FLAT subwoofers! The new ETON MW FLAT series scores with its particularly flat dimensions - rich bass performance and yet extremely flat. Ideal for all spare wheel recessed subwoofers or enclosures that need to be flat. Extremely powerful ferrite magnets and large, heavy-duty 2 x 2 Ω voice coils with pressed paper cone and long-throw surround in a special design. Extremely torsion-resistant die-cast aluminum baskets and high-quality clamp connection terminals. One of the most powerful flat subwoofers in its class!

  • Liên hệ
  • 36
NHẬP THÔNG TIN ĐỂ ĐƯỢC TƯ VẤN

Liên hệ đặt hàng nhanh chóng qua

300 mm (12") flat subwoofer with pressed, air-dried paper cone. Extremely torsion-resistant, powder-coated die-cast aluminum basket, with special design for extremely flat installation dimensions. Heavy-duty 2 x 2 Ω double voice coil with ventilation. Extremely strong ferrite magnet with large pole core hole and additional ventilation holes for maximum performance! High-quality clamp terminals. 2 x 300 W RMS rated power handling. 2 x 450 W music power handling. 86.2 dB characteristic sound pressure. Outer diameter 328 mm. Installation depth 108 mm. Cut-out diameter 288 mm. Engineered in Germany.MW 12 FLATImpedance2x2 ΩNominal power (RMS600 WMusic power900 WSound pressure level 86.2 dBOuter diameter 328 mmInstallation depth108 mm
Nominal impedance
Zn
2x2
Ω
Total moving mass (incl. air mass)
MMD
213.0
g
DC resistance
Re
3.8
Ω
Effective piston area
SD
510
cm2
Voice coil inductance
Le
3.05
mH
Resonance frequency TSP
fr
37.6
Hz
Force factor
BLxl
18.60
Tm
Suspension compliance
CMS
0.08
mm/N
Mechanical Q
QMS
8.75
Xmax mechanical
+/-
38.0
mm
Electrical Q
QES
0.59
Equivalent air vol. of suspension
VAS
31.02
dm3
Total Q
QTS
0.55
Characteristic SPL 1W / 1 m
86.5
dB
Mechanical resistance
RMS
7.22
kg/s
Rated power
500/700
W
magnet material
Ferrit
voice coil diameter
63
mm
Overall diameter
325
mm
Cutout diameter
285
mm
Installation depth
106
mm
Terminal
4
qmm
Weight
7.1
kg
technische_daten_impendanz_image
